Shared projects

MRF24 Outlet

by DrYerzinia.
Top
Bottom

2 layer board of 1.34x2.09 inches (34.04x52.96 mm).
Shared on September 1st, 2013 23:01.

Control AC Current remotely with a MRF24MA Tranciver. For more details check out my site, and go here to control the light in my work room

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

USB MRF24J40MA Controller

by DrYerzinia.
Top
Bottom

2 layer board of 2.01x3.31 inches (51.05x84.10 mm).
Shared on September 1st, 2013 09:00.

Lets you send commands to other MRF24J40MA wireless modules via USB Serial interface. For more details see my site

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

XBee USB Serial Converter

by DrYerzinia.
Top
Bottom

2 layer board of 1.31x1.76 inches (33.27x44.73 mm).
Shared on August 31st, 2013 02:12.

Control XBee Tranciver from via USB. More details on my site

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

FT817USB

by DrYerzinia.
Top
Bottom

2 layer board of 2.11x1.77 inches (53.62x44.98 mm).
Shared on August 29th, 2013 08:12.

Circuit board to transmit with my Yaesu FT817 radio via USB port for code, bom, and other details look on my site

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

Inline Amplifier

by DrYerzinia.
Top
Bottom

2 layer board of 1.51x3.41 inches (38.25x86.64 mm).
Shared on August 29th, 2013 06:14.

This board uses a LM386 chip to boost small audio signals to higher levels for speakers or input to other devices. For more details take a look at my site

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project
