3PDT Daughter Board
by
mmolteratx.
2
layer board of
1.79x0.90
inches
(45.42x22.89
mm).
Shared on
August 5th, 2014 21:57.
For true bypass with basic onboard power filtering.
Schematic: https://dl.dropboxusercontent.com/u/8021347/Switch.png
3PDT TBP V6 copy
by
IvIark.
2
layer board of
0.80x1.00
inches
(20.32x25.43
mm).
Shared on
August 5th, 2014 21:42.
Blue Taiwan switch true bypass board V6
Powerboard3
by
jseismo.
2
layer board of
2.60x2.91
inches
(66.07x73.84
mm).
Shared on
August 5th, 2014 20:19.
Relay board for Beaglebone Black
USBMiniSw
by
AtomSoft.
2
layer board of
0.73x1.15
inches
(18.47x29.08
mm).
Shared on
August 5th, 2014 18:29.
Untested Simple USB Switch (DUAL) R1 - 0805 - 10k u$1 - MAX4899AE U$3-U$4 - MINI B USB U$7 - USB Type A U$9 - JS102011SAQN U$10 - TLV70033DDCT
Directional Coupler
by
K9IVB.
2
layer board of
2.01x2.11
inches
(50.95x53.52
mm).
Shared on
August 5th, 2014 16:05.
Directional Coupler for RF Power Measurements
