DAC Wing
by
DiegoRosales.
2
layer board of
0.82x1.09
inches
(20.93x27.79
mm).
Shared on
July 7th, 2014 15:23.
DAC Wing for the Papilio FPGA Platform
LedPcb
by
jmiguelff.
2
layer board of
5.21x3.84
inches
(132.21x97.41
mm).
Shared on
July 7th, 2014 14:42.
This is as 4 digit LED matrix controlled by MAX6953. It can be controlled using I2C and uses 3V3 or 5V as supply voltage.
PIC 18-pin Barebone
by
Rasyoung.
2
layer board of
2.39x2.93
inches
(60.66x74.42
mm).
Shared on
July 7th, 2014 14:04.
pic16F88 with 5v regulator
SIP8 Adapter
by
Jubal81.
2
layer board of
0.91x0.45
inches
(23.16x11.43
mm).
Shared on
July 6th, 2014 19:28.
SOIC8 to SIP8
HM-10 Breakout v.9.9
by
Ladvien.
2
layer board of
0.95x1.44
inches
(24.00x36.58
mm).
Shared on
July 6th, 2014 15:37.
Update: 7/6/14 – Corrected silkscreen error.
