Heater Control
by
Evan.
2
layer board of
1.50x2.35
inches
(38.13x59.72
mm).
Shared on
November 1st, 2013 23:45.
Control Board for Gene Cafe
ATTiny Sewable
by
voidptr.
2
layer board of
0.80x0.80
inches
(20.19x20.19
mm).
Shared on
November 1st, 2013 22:32.
Modeled after the Adafruit Gemma and Sparkfun LilyTiny.
Same size as LilyTiny, but breaks out all 5 I/O pins available on the ATTiny.
Breaks out an ISP header on the back.
Sewable WS2812 Pixel
by
voidptr.
2
layer board of
0.60x0.60
inches
(15.16x15.16
mm).
Shared on
November 1st, 2013 22:27.
Modeled after the Adafruit Neopixel
Tiny Header Board 1.2 m2
by
boyanov.
2
layer board of
0.90x1.40
inches
(22.96x35.66
mm).
Shared on
November 1st, 2013 11:17.
Tiny header board for the Atmel AVR ATtiny chips in DIP-8 such as ATtiny 25/45/85 (ATtiny13 as well)
The goal is to have a board that you can start using right a way, contains the minimum required components to run properly and will even let you prototype simple projects without using a breadboard.
Circuit is available at 123d.circuits.io
Pingbot Jameco Kit v12
by
Tomdf.
2
layer board of
1.49x1.50
inches
(37.90x38.02
mm).
Shared on
October 30th, 2013 23:45.
Pingbot Jameco kit v12
