FreezeFrame
by![](../../../gravatar.com/avatar/9a0ff63bd1ed98463718ee85f86a68b9ea98.jpg?s=16)
2
layer board of
2.10x1.38
inches
(53.29x35.05
mm).
Shared on
July 30th, 2013 23:17.
Freeze Frame / Shadow Wall controller See here for more info.
TI CC3000 WiFi Breakout
by![](../../../gravatar.com/avatar/7065c94f9bf4fc222d774708966d394cea98.jpeg?s=16)
2
layer board of
1.15x0.80
inches
(29.24x20.32
mm).
Shared on
July 30th, 2013 23:10.
This is a minimal board to break out the Texas Instruments CC3000 WiFi Module.
C1: 1pF 0402
L1, L2: do not populate
C2: 4.7uF 0805
C3: 100nF 0603
You may adjust all component values to taste (only C1’s value is important.)
FemtoI2C_r1
by![](../../../gravatar.com/avatar/3f6301130e7bdf721decf4ba1b2f9891ea98.jpeg?s=16)
2
layer board of
1.35x0.80
inches
(34.24x20.32
mm).
Shared on
July 30th, 2013 23:00.
SOIC Breakout board for the NXP PCA9555A chip. Provides additional GPIO pins to any microcontroller.
Barom Board
by![](../../../gravatar.com/avatar/bcb84723b91bb00d11c72a731230fbfcea98.jpg?s=16)
2
layer board of
0.45x0.61
inches
(11.33x15.44
mm).
Shared on
July 30th, 2013 22:13.
MPL115A2 + TMP102 Sensor Board
Dimmer
by![](../../../gravatar.com/avatar/bcb84723b91bb00d11c72a731230fbfcea98.jpg?s=16)
2
layer board of
1.10x0.73
inches
(27.94x18.47
mm).
Shared on
July 30th, 2013 22:13.
Dimmer with Current Sensor
