BM23 Adapterboard
by
KapelMa2706.
2
layer board of
2.30x1.74
inches
(58.42x44.15
mm).
Shared on
November 3rd, 2016 10:58.
BM23 Adapterboard is a small adapterboard for the BM23 from Microchip. This adapterboard allows you to control the Bluetoothmodule with a microcontroller or to program the BM23.
(Note: This was designed for testing the BM23 and was used in our project the BlueMeter)
SourDough 8ch Logic Level Converter - 3.3v to 5v DC
by
PhantomicLabs.
2
layer board of
0.71x1.01
inches
(18.06x25.68
mm).
Shared on
November 3rd, 2016 06:18.
BOM — TXB0108PWR - TI logic conveter chip. Two 0.1uF Caps, 0805. 100k resistor, 0805. Two 10-position male pin headers, 2.54mm pitch.
LSM6DSL breakout
by
Bunsen.
2
layer board of
0.66x0.76
inches
(16.66x19.20
mm).
Shared on
November 3rd, 2016 04:25.
Breakout board for ST Micro LSM6DSL accelerometer/gyro
SI7006 Breakout
by
Bunsen.
2
layer board of
0.68x0.46
inches
(17.30x11.58
mm).
Shared on
November 3rd, 2016 04:25.
Breakout board for SiLabs SI7006 temperature/humidity sensor
DPAK/D2PAK/SOT-223/SOT23 to PTH adapter board
by
Bunsen.
2
layer board of
0.46x0.81
inches
(11.58x20.47
mm).
Shared on
November 3rd, 2016 04:25.
Adapter board for using 3-pin transistors and regulators on a breadboard. Fits TO-263, TO-252, SOT-223, and SOT-23 packages. Includes pads for passives linking pins 1-2, 2-3, and 1-3 for regulator caps, pullup resistors, and such.
