Gamecube HDMI 1.4
by
citrus3000psi.
2
layer board of
1.42x1.62
inches
(36.02x41.05
mm).
Shared on
October 19th, 2016 12:24.
BK8000L Breakout Board
by
jonhllstrm.
2
layer board of
1.16x1.54
inches
(29.39x39.22
mm).
Shared on
October 19th, 2016 11:59.
BK8000L Bluetooth audio module breakout board
SIMfacer
by
marble.
2
layer board of
1.00x0.80
inches
(25.43x20.32
mm).
Shared on
October 19th, 2016 07:32.
A SIM interfacing card for UART
| Part(s) | Value |
|---|---|
| C1, C2 | according to crystal (e.g. 15pF) |
| C3 | 1uF |
| C4 | 100uF |
| IC1 | 74AC04D |
| Q1 | NPN SOT23 BEC (e.g. MMBT2222A) |
| R1 | 1M |
| R2, R3 | 1K |
| R4, R5 | 10K |
| SIM1 | C707-10M006-136-2 |
| X1 | 3.57 MHz or 3.686 MHz |
RX02 Emulator Shield v4rev2 (2N7000-based version)
by
AK6DN.
4
layer board of
3.91x2.11
inches
(99.24x53.49
mm).
Shared on
October 19th, 2016 05:27.
RX02 Emulator Arduino Mega Shield v4rev2
Documentation: https://drive.google.com/open?id=0B7Csc-dWWfTYR3plTmtWd2VtWlU
Software: https://github.com/AK6DN/rx02_emulator
PiAQ v0.2
by
CRTLabs.
2
layer board of
2.56x2.23
inches
(65.02x56.52
mm).
Shared on
October 19th, 2016 01:03.
