Touch Pixel v2
by
TreySch.
2
layer board of
3.20x2.79
inches
(81.28x70.87
mm).
Shared on
May 13th, 2017 01:51.
This is the PCB used to help funding for the Touch Screen Exhibit. Required parts: APA102C - 3; 1x17 Fml Hdr - 2; 10M Resistor (1206in) - 3; Potentiometer - 1; Power Slide Switch - 1; SP3D Slide - 1. This design uses the Pololu A-Star Micro (#3101) with surface mount header pins, except for MOSI and SCK
Button Board
by
TreySch.
2
layer board of
1.82x1.99
inches
(46.23x50.57
mm).
Shared on
May 13th, 2017 01:51.
for the touchscreen exhibit. this board will be used as a game cartridge that interfaces with the rest of the exhibit. This board holds a DMOS 8 channel chip, 2 RGB SMD LED packages, and a teensy 3.2. The board is connected via two 1x7 header sockets and three SMT 6-32 standoffs
LED Board v2
by
TreySch.
2
layer board of
0.90x0.90
inches
(22.89x22.89
mm).
Shared on
May 13th, 2017 01:50.
Break out board of APA102-C RGB LEDs. This board can be strung together into a any length with any number of LEDs. The main constraints are supplying enough power periodically because the LEDs draw ~50mA per and will cause a voltage drop. APA102-C LEDs use SPI to control the LEDs. These are extremely more tolerant than the WS2812 LEDs that utilize a single PWM to address the LEDs for data timing.
rc2014_8085b
by
ancientcomputing.
2
layer board of
3.99x2.00
inches
(101.27x50.80
mm).
Shared on
May 12th, 2017 22:19.
8085 CPU Board. Designed for RC2014.
Model M USB driver
by
a1k0n.
2
layer board of
5.44x0.68
inches
(138.07x17.37
mm).
Shared on
May 12th, 2017 20:14.
Replace the guts of an IBM Model M keyboard w/ USB.
