File:Bandpass sampling depiction.png
From Wikimedia Commons, the free media repository
Size of this preview: 800 × 563 pixels. Other resolutions: 320 × 225 pixels | 640 × 450 pixels | 938 × 660 pixels.
Original file (938 × 660 pixels, file size: 29 KB, MIME type: image/png)
Summary[edit]
| Description |
English: The top 2 graphs depict Fourier transforms of 2 different functions that produce the same results when sampled at a particular rate. The baseband function is sampled faster than its Nyquist rate, and the bandpass function is undersampled, effectively converting it to baseband. The lower graphs indicate how identical spectral results are created by the aliases of the sampling process.
|
| Date | |
| Source | Own work |
| Author | Bob K |
