Summary[edit]
| Description |
English: Response of the proportional term in an open-loop control mode. Different values are taen for Kp; whereas KI & KD are fixed.
العربية: وصف لدور الحد التناسبي في حلقة تحكم مفتوحة. تم تثبيت الحدين الاخرين التكاملي والتفاضلي.
|
| Date | |
| Source | Own work |
| Author | Email4mobile |
| Permission (Reusing this file) |
Free use. |
Licensing[edit]
 |
I, the copyright holder of this work, release this work into the public domain. This applies worldwide. In some countries this may not be legally possible; if so: I grant anyone the right to use this work for any purpose, without any conditions, unless such conditions are required by law.
|
