PowerBarB4

by AndiceLabs.
Top
Bottom

2 layer board of 0.83x2.15 inches (21.06x54.71 mm).
Shared on August 30th, 2016 04:30.

Simple BeagleBone power supply

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

Raspberry Pi UART and I2C breakout

by AndiceLabs.
Top
Bottom

2 layer board of 1.50x0.90 inches (38.20x22.96 mm).
Shared on September 12th, 2014 19:41.

Simple FTDI interface for console UART and I2C. Allows you to easily use an FTDI-compatible cable (ex: Adafruit FTDI-friend) to gain console access to the Raspberry Pi.

Connectors:

  • Female header: Sullins S7116-ND
  • FTDI: FCI 68016-106HLF
  • I2C: TE 640457-4
  • I2C mate: TE 3-643814-4

PiConsole

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

PowerBarB2

by AndiceLabs.
Top
Bottom

2 layer board of 0.83x2.15 inches (21.06x54.71 mm).
Shared on December 23rd, 2013 03:49.

A BeagleBone power supply for battery use. For more information see this page.

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

GoodFET42

by AndiceLabs.
Top
Bottom

2 layer board of 2.25x1.30 inches (57.15x33.02 mm).
Shared on October 13th, 2013 21:15.

GoodFET42 by Travis Goodspeed. Modified to use 0805 parts, fit into a Hammond 1593K enclosure, and use a type B USB receptacle.

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project
