Shared projects
blinkyclock.kicad_pcb
by
ExplodingLemur.
2
layer board of
1.61x1.31
inches
(40.79x33.17
mm).
Shared on
May 13th, 2017 21:11.
antenna_analyzer_rev7.kicad_pcb
by
ExplodingLemur.
2
layer board of
3.91x3.11
inches
(99.21x78.89
mm).
Shared on
December 25th, 2016 20:20.
K6BEZ Antenna Analyzer Project from http://www.360workbench.com/
jar_of_fireflies.kicad_pcb
by
ExplodingLemur.
2
layer board of
1.51x1.39
inches
(38.25x35.20
mm).
Shared on
October 2nd, 2016 04:19.
Test board for a jar of fireflies project. https://github.com/ExplodingLemur/jar_of_fireflies
ShopBot Interface
by
ExplodingLemur.
2
layer board of
2.91x1.06
inches
(73.81x26.82
mm).
Shared on
August 21st, 2015 02:08.
Parallel port interface to a ShopBot stepper driver board
cypress fx2 logic analyzer v1.1
by
ExplodingLemur.
2
layer board of
1.40x1.60
inches
(35.66x40.74
mm).
Shared on
June 6th, 2015 06:56.
Buffer board for a Cypress FX2 EZ-USB dev board, can be used with Sigrok as a logic analyzer. https://github.com/ExplodingLemur/ezusb-logicanalyzer http://blog.explodinglemur.org/?p=37
