Programmer for Alice-SIP
by
Firebirduino.
2
layer board of
1.24x0.62
inches
(31.39x15.65
mm).
Shared on
December 28th, 2016 18:21.
Programmer for the low profile Alice-SIP modules.
R1=R2=R3=1K, C1=C2=0.1uf, C3=10uf. All are in 0805.
NanoBoy Zero with SD
by
Firebirduino.
2
layer board of
1.90x0.71
inches
(48.29x17.91
mm).
Shared on
August 27th, 2016 13:16.
Arduino Zero with SD memory Card.
The ATSAMD21G18A based NanoBoy Zero is fully compatible to the Arduino Zero. The extra features Include dual 3.3V regulators, SWD debugger interface, on-board user button, Lipo Charger and SD memory card slot.
See details at www.firebirduino.com
NanoBoy MK20DX
by
Firebirduino.
2
layer board of
1.71x0.72
inches
(43.31x18.19
mm).
Shared on
August 13th, 2016 04:44.
The 34 pin MK20DX256 based NanoBoy Mini stamp is Arduino pin compatible to the Teensy 3.2. The extra features Include dual 3.3V regulators, 32KHz crystal, buffered D13 LED, a user button and SWD debugger interface for the Freescale KDS.
Easy-to-read pin labels include native signal names for professionals.
See details at www.firebirduino.com
TFT display Shield for UNO, Alice Lite and Teensy Pad
by
Firebirduino.
2
layer board of
2.02x0.61
inches
(51.38x15.47
mm).
Shared on
August 9th, 2016 06:29.
A small Shield for the popular 2.2" TFT display. Only needs 3 through hole parts, 74HC4050N, 100 ohm resistor and 0.1uf cap, plus connectors. Arduino control signals: D9->D/C, D10->CS. Fully tested.
See the product at www.firebirduino.com
STM32 F4 Stamp Mini Breakout
by
Firebirduino.
2
layer board of
1.61x1.01
inches
(40.79x25.55
mm).
Shared on
June 23rd, 2016 04:28.
A new STM32F405RGT mini F4stamp is based on Frank Zhao’s design for DIY makers.
More details and schematic available at www.firebirduino.com
