OSH Park
Profile for Rockit-Frog
Shared projects
SOIC and SSOP to PTH 16 Pin
by
Rockit-Frog.
2
layer board of
0.83x0.63
inches
(20.98x15.90
mm).
Shared on
October 16th, 2016 09:21.
Adaptor board for using 16 pin SOIC or SSOP parts on a breadboard
Poison Dart
by
Rockit-Frog.
2
layer board of
1.24x1.04
inches
(31.39x26.31
mm).
Shared on
February 5th, 2015 08:58.
MOSFET treble boost Project doc is at Rock.it-Frog.com
CV to Potentiometer
by
Rockit-Frog.
2
layer board of
2.13x1.45
inches
(54.10x36.70
mm).
Shared on
January 16th, 2015 09:11.
CV input controls potentiometer or variable resistors.
Download the documentation and sample code here: Docs and code
CV to Potentiometer SMD
by
Rockit-Frog.
2
layer board of
2.12x1.06
inches
(53.85x26.80
mm).
Shared on
January 16th, 2015 09:11.
CV input to potentiometer output controlled by an MCU. Download the documentation and sample code here: Docs and code
PEQ Two Band
by
Rockit-Frog.
2
layer board of
1.69x1.43
inches
(42.93x36.32
mm).
Shared on
January 4th, 2015 02:50.
PTH version of two band EQ
