Toradex HMI Adapter V1.1
by
Toradex.
2
layer board of
3.55x3.94
inches
(90.14x100.15
mm).
Shared on
May 10th, 2017 06:53.
Toradex HMI Adapter is an interface board which plugs on to the Toradex Viola Plus Carrier Board and provide the following industrial interface:
- Wide range input power supply (7V-36V)
- 1x Isolated CAN Bus
- 2x Isolated half duplex RS485/MODBUS
- 1x Isolated RS232
- Upto 8x Isolated GPIO
- 1x Buzzer
- Serial Flash Memory
Click here for more details about Toradex HMI Adapter.
Toradex RGB-VGA Adapter V1.0
by
Toradex.
2
layer board of
2.38x1.27
inches
(60.33x32.31
mm).
Shared on
April 26th, 2017 05:03.
Toradex RGB-VGA Adapter is an interface board which accepts digital RGB signal and provide analog VGA output. The RGB-VGA Adapter uses Analog Devices ADV7125 Video DAC IC to convert digital RGB signals to analog VGA signals. The input connector of the RGB-VGA Adapter follows the Unified EDT display interface, which is available on the Toradex Carrier Boards.
Click here for more details about Toradex RGB-VGA Adapter.
Toradex Generic LCD Adapter V2.1
by
Toradex.
2
layer board of
1.19x1.58
inches
(30.12x40.11
mm).
Shared on
March 23rd, 2017 13:31.
Generic Display Adapter is an interface board which is used to connect number of TFT LCDs which supports 40 pin connector “Generic Standard”. The Generic Standard pinout is supported by many LCD manufacturers. The Generic Display Adapter provides 18 bit RGB signal along with 4-wire resistive touch interface on the same 40 pin connector. The input connector of the Generic Display Adapter follows the Unified EDT display interface, which is available on the Toradex Carrier Boards.
Click here for more details about Generic Display Adapter.
