Mini OLED breakout

by

2 layer board of 0.50x0.46 inches (12.62x11.68 mm).
Shared on December 25th, 2013 02:24.

Small breakout protoboard for -> http://www.buydisplay.com/default/mp3-oled.html

using the built in regulator. Pins/caps should be reasonably obvious if you compare it to the schematic in the “interface” datasheet. Untested so far.

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

LED stick connector triangle

by

Zephod.

2 layer board of 0.67x0.58 inches (16.92x14.66 mm).
Shared on December 11th, 2013 01:19.

Configurable WS2812b LED Stick connector triangle with optional center LED.

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

60 degree LED-strip connector board

by

Zephod.

2 layer board of 0.88x0.61 inches (22.35x15.44 mm).
Shared on November 27th, 2013 00:36.

Allows LED sticks to be mounted in triangles.

Order board. Download. Permalink. Embed order link.

Copy this HTML into your page to embed a link to order this shared project

LED-strip connector - T crossing

by

Zephod.

2 layer board of 0.60x0.50 inches (15.27x12.70 mm).
Shared on November 27th, 2013 00:36.

Configurable T-crossing for LED-strips. The solder jumpers can be used to connect either side to VCC/GND and let the center-data flow from any header to any other.
