OSH Park
Profile for gcharles
Shared projects
PH_interface
by
gcharles.
2
layer board of
1.58x1.31
inches
(40.18x33.38
mm).
Shared on
October 31st, 2015 12:17.
atlas ph interface
slave
by
gcharles.
2
layer board of
2.33x1.74
inches
(59.21x44.22
mm).
Shared on
October 31st, 2015 12:17.
ph temp
R8875_ARDUINO_DUE
by
gcharles.
2
layer board of
3.24x2.06
inches
(82.32x52.37
mm).
Shared on
October 31st, 2015 12:17.
R8875_ARDUINO_DUE interface
Xbee_interface
by
gcharles.
2
layer board of
1.40x1.69
inches
(35.51x42.82
mm).
Shared on
October 31st, 2015 12:15.
xbee interface pcb
ST7920_INTERFACE_spi
by
gcharles.
2
layer board of
2.36x1.00
inches
(59.89x25.37
mm).
Shared on
November 10th, 2013 12:16.
ST7920_INTERFACE_spi
