TI-99-32k-sideport rev4
by
jedimatt42.
2
layer board of
3.11x2.23
inches
(78.94x56.72
mm).
Shared on
April 19th, 2017 19:07.
TI-99/4A 32k sideport memory expansion card - See http://ti994a.cwfk.net/32k.html for BOM and project details.
TI-99-32k-sideport-edgecard.zip
by
jedimatt42.
2
layer board of
0.71x2.26
inches
(17.98x57.33
mm).
Shared on
November 11th, 2016 05:56.
TI-99/4A 32k sideport card 44pin header to edgecard adapter.
This is a companion for the 32k sideport expansion card available for the TI-99/4a : see this thread on Atariage
This board and a right angle female header connector allows connecting things like the TI PEB, or standalone disk drives downstream of the 32k expansion board.
TI-99/4A Side Port Breadboard Adapter
by
jedimatt42.
2
layer board of
3.21x2.31
inches
(81.46x58.62
mm).
Shared on
July 30th, 2016 05:04.
breadboard breakout for TI 99 home computer side expansion port.
Designed to work with a 44 pin edge connector, and the side port extension cable as produced by Hello Cables
See Atariage thread here: Atariage thread: side-port-breadboard-adapter-like-pi-cobler
endlos99-flashrom99-rev2-TI-99
by
jedimatt42.
2
layer board of
3.94x3.15
inches
(100.15x80.09
mm).
Shared on
June 12th, 2016 17:50.
This board was designed by Ralph Benzinger.
The cartridge allows playing ROM images stored on an SD card on an unexpanded TI 99/4A, and so much more with an expanded TI.
For complete details see the homepage
TI 99 USB Keys
by
jedimatt42.
2
layer board of
1.91x2.16
inches
(48.41x54.79
mm).
Shared on
February 14th, 2016 16:32.
USB keyboard adapter for TI-99/4a
