OSDFC_V2
by
skyscraper.
4
layer board of
3.05x1.39
inches
(77.39x35.41
mm).
Shared on
April 6th, 2017 09:46.
OSD and FC
FPVHUB EZRSSI
by
skyscraper.
2
layer board of
1.05x0.46
inches
(26.70x11.58
mm).
Shared on
January 28th, 2017 09:39.
Analog rssi for EZUHF. Turns the EZUHF PWM signal into a 0 to 3V analog output. Now tested and working nicely
apm sub hub
by
skyscraper.
4
layer board of
1.59x1.59
inches
(40.39x40.39
mm).
Shared on
April 6th, 2016 01:04.
sub hub pcb for distributed apm system. The subhub is designed to go into a wing. It allows the wing electonics to be connected to the fuselage with a single 4 way connector. The connector also provides power output to the servos of 5 volts at up to 2 Amps at from 7 to 25 volts input . The protype board can control 2 servos, a gps , an RC receiver , an analog input such as an airspeed sensor, and an I2c input such as a magnetometer
Quantracker Air OSD V2.2
by
skyscraper.
4
layer board of
2.24x1.17
inches
(56.79x29.62
mm).
Shared on
July 24th, 2015 07:18.
FPV OSD using an STM32F4
Quantracker Air OSD v2.1
by
skyscraper.
4
layer board of
2.24x1.17
inches
(56.79x29.59
mm).
Shared on
April 26th, 2015 15:54.
Quantracker Air OSD V2.1
