HenryLCD

by KO4XL.
Top
Bottom

2 layer board of 1.74x1.10 inches (44.15x27.94 mm).
Shared on March 4th, 2014 05:50.

Henry method 2-wire LCD interface. See Thomas Henry’s article in the February 2014 issue of Nuts and Volts. (This board design is released with the Author’s and Publisher’s permission.)
