LCD4x1 v2

by physnoct.
Top
Bottom

2 layer board of 1.10x1.70 inches (27.94x43.23 mm).
Shared on March 8th, 2014 17:01.

Atmel ATmega169 with LCD 4x1 (Lumex LCD-S401M16KR) and 4 buttons (C&K PTS635SL25SMTR LFS). BOM and applications available at http://sourceforge.net/projects/lcd4x1module/
