ATtiny85V Energy Harvesting- Sensor Platform - Rev A.

by siahman.
Top
Bottom

2 layer board of 1.82x1.49 inches (46.23x37.87 mm).
Shared on May 6th, 2014 13:40.

Includes two sensor inputs, solar panels and buck regulator with settable hysteresis. Runs on 0.550µA quiescent current, with wake up from power good interrupt. Able to harvest energy from included solar panels or from piezo input, while sensing on two ADC’s.
