nixieAux.brd
by
capricorn_one.
2
layer board of
2.56x0.59
inches
(65.02x15.01
mm).
Shared on
April 14th, 2017 01:15.
nixiePlanter Jacks and Switches
esp-12 2side v2
by
cperiod.
2
layer board of
1.06x2.03
inches
(26.82x51.59
mm).
Shared on
April 14th, 2017 00:46.
Basic ESP-12 dev board, derived from a single-sided home-etched version using (mostly) through-hole components I have on hand. 1x AMS1117-33, 4x 10k R, 2x 10-22uF, 1x 100pF, 1x slide switch, 1x screw terminal, 2x tact switches, (optional) LED+resistor, assorted headers (I mount my ESP-12’s on 2mm headers).
You can also swap the AMS1117 with a TO-92 HT7333 for low quiescent power applications (i.e. 3.7v Li-ion).
PE3 PWM Driver P-CH (1-18-2016)
by
matthew.martin8.
2
layer board of
0.72x0.55
inches
(18.16x13.97
mm).
Shared on
April 13th, 2017 20:49.
PE3 PWM Driver P-CH (1-18-2016)
Ys
by
kenbrownlab.
2
layer board of
3.05x2.14
inches
(77.47x54.31
mm).
Shared on
April 13th, 2017 20:32.
motor_shield__SD_v1.1.brd
by
sshriya.
2
layer board of
3.04x2.05
inches
(77.17x52.07
mm).
Shared on
April 13th, 2017 19:17.
Senior design Motor Shield
