OSH Park
Shared projects
xlamp4i.brd
by
dword1511.
2
layer board of
0.59x0.59
inches
(15.01x15.01
mm).
Shared on
April 4th, 2017 02:09.
MCPCB substitute for Cree XLamp. Intended to work with thermal glue or epoxy. Individual connections.
xlamp4s.brd
by
dword1511.
2
layer board of
0.59x0.59
inches
(15.01x15.01
mm).
Shared on
April 4th, 2017 02:09.
MCPCB substitute for Cree XLamp. Intended to work with thermal glue or epoxy. 4-series configuration. With 0603 1- and 2-LED bypass jumpers.
Flight Controller
by
ottojo.
2
layer board of
2.08x2.77
inches
(52.81x70.38
mm).
Shared on
April 3rd, 2017 22:49.
101003-A JTAG Prog Adapter Osh 2-15-17.zip
by
NicholasJohnson14.
2
layer board of
0.83x0.67
inches
(21.08x16.89
mm).
Shared on
April 3rd, 2017 21:43.
MSP 430 JTAG Programming Adapter
14226^5
by
epccs.
2
layer board of
2.38x2.10
inches
(60.33x53.37
mm).
Shared on
April 3rd, 2017 20:45.
RPUadpt
Shield for full duplex RS-422 over CAT5. Its a multidrop bus that works with serial bootloaders (e.g. optiboot, xboot… ) and avrdude.
