Shared projects
PIC16F18857 Protoboard
by
TheHammer.
2
layer board of
1.40x0.71
inches
(35.59x18.03
mm).
Shared on
March 28th, 2017 09:49.
PIC Chip Breadboard Prototyping PCB
stamp_v5.zip
by
mckvack.
2
layer board of
0.64x1.14
inches
(16.23x29.03
mm).
Shared on
March 28th, 2017 09:04.
DIP Flip Whixr Trick (Rev. A)
by
joegrand.
2
layer board of
1.29x0.98
inches
(32.79x24.77
mm).
Shared on
March 28th, 2017 01:15.
This DIP goes both ways (www.grandideastudio.com/portfolio/sneaky-circuits/)
14145^4
by
epccs.
2
layer board of
2.38x2.10
inches
(60.33x53.37
mm).
Shared on
March 27th, 2017 22:21.
RPUftdi
Shield for full duplex RS-422 over CAT5 with USB for a host. Its a multidrop bus that works with serial bootloaders (e.g. optiboot, xboot… ) and avrdude.
Split Supply Power Distribution Board V2
by
Neon_Bulb_Dude.
2
layer board of
3.29x1.35
inches
(83.52x34.29
mm).
Shared on
March 27th, 2017 20:59.
***NOTE: You can put the capacitors on the bottom side of the board to give easier access to the 3-pin connectors.
