OSH Park
Shared projects
MinerRide_MainBoard
by
cwinans.
2
layer board of
3.90x2.10
inches
(99.16x53.44
mm).
Shared on
July 25th, 2014 21:42.
MinerRide_OmniWheelBoard
by
cwinans.
2
layer board of
1.65x1.75
inches
(42.01x44.55
mm).
Shared on
July 25th, 2014 21:42.
MinerRide_RelayBoard
by
cwinans.
2
layer board of
3.25x1.65
inches
(82.65x42.01
mm).
Shared on
July 25th, 2014 21:42.
XBee Sensor Node V1.1
by
FamousJameous.
2
layer board of
2.66x1.96
inches
(67.51x49.73
mm).
Shared on
July 25th, 2014 18:22.
Updated version of the XBee Sensor Node
MC9S08QE64 Miniboard
by
OldMicroGuy.
2
layer board of
1.78x0.80
inches
(45.11x20.32
mm).
Shared on
July 25th, 2014 16:54.
For details click here
