Arduino Dual H-Bridge
by
jlewis184.
2
layer board of
2.28x2.09
inches
(58.01x53.01
mm).
Shared on
July 23rd, 2014 18:12.
Dual h-bridge motor driver and solenoid driver with an Arduino compatible controller
Snowing Effect
by
Lomikar.
2
layer board of
1.79x1.50
inches
(45.39x38.10
mm).
Shared on
July 23rd, 2014 15:08.
Generates a random snowflakes slowly filling a Matrix 8x8 from bottom to top. The snow melts too so the top is rarely reached.
A standard MAX7219 8x8 LED matrix module from eBay (not included) is controlled by ATTINY85 controller. Buttons change effect speed.
With own software this can be used for other applications as well. I used same module for dice and another game with MAX7219 driving eight 7 segment displays.
Have fun!
OpenTekModule v0.03
by
mchamster.
2
layer board of
1.40x0.39
inches
(35.56x9.83
mm).
Shared on
July 22nd, 2014 21:25.
OpenTekModule v0.03
FuelTankAdapter
by
jancumps.
2
layer board of
2.16x1.06
inches
(54.76x26.82
mm).
Shared on
July 22nd, 2014 21:17.
Adapt E14 Fuel Tank boosterpack to Hercules Launchpad
Audio limiter/leveler by W2AEW
by
LRY.
2
layer board of
0.79x1.85
inches
(19.99x46.99
mm).
Shared on
July 22nd, 2014 15:24.
Audio limiter/leveler by W2AEW, checkout these videos: https://www.youtube.com/watch?v=1h0FZJYXQ_w and https://www.youtube.com/watch?v=pUii_pDQxg8&list=UUiqd3GLTluk2s_IBt7p_LjA
