Counter v4.01
by
thatdecade.
2
layer board of
1.03x0.90
inches
(26.21x22.78
mm).
Shared on
January 2nd, 2014 16:53.
Dual digit number display for LaserTag LTAR tagger.
Source: http://codebender.cc/sketch:26550
More Info: http://www.westaby.net/2013/12/ltar-display/
WauCard V. 1.1.0
by
ElectricCoffee.
2
layer board of
2.42x2.36
inches
(61.60x59.99
mm).
Shared on
January 2nd, 2014 16:32.
An updated version of the WauCard, this time with added LEDs; one on pin 13 and one for TX and RX respectively
uNRFv2 Z mod
by
tterev3.
2
layer board of
1.43x0.76
inches
(36.20x19.18
mm).
Shared on
January 2nd, 2014 14:46.
modified version of uNRFv2 with trace antenna and mounting holes
WauCard Micro Controller
by
ElectricCoffee.
2
layer board of
2.42x2.36
inches
(61.60x59.99
mm).
Shared on
January 2nd, 2014 14:35.
A simple thru-hole Microcontroller board based on the Arduino’s schematic, it is however incompatible with Arduino Shields
Metal Detector
by
Scott216.
2
layer board of
2.06x1.65
inches
(52.32x41.86
mm).
Shared on
January 2nd, 2014 00:36.
Ref: Silicon Chip June 2002
Thomas Scarborough
Eagle board files are on GitHub
PDF Instructions
04106021
