MAX31725 Breakout
by
Awesomenesser.
2
layer board of
0.69x0.45
inches
(17.45x11.43
mm).
Shared on
August 1st, 2013 13:20.
Small breakout for the MAX31725 i2c temp sensor. Full 32 address range available using the 6 double jumpers. Pullups for SDA, SCL, and OS are available. Maxim Product Page Board Schematic
Bluetooth rn-52 audio module
by
Segura.
2
layer board of
1.31x1.01
inches
(33.25x25.68
mm).
Shared on
August 1st, 2013 08:53.
bluetooth module v1.2
Inductive spark plug sensor v2
by
Hustin13.
2
layer board of
1.59x1.00
inches
(40.34x25.40
mm).
Shared on
August 1st, 2013 02:02.
Senses spark plug ignition using a grounded sensor wire wrapped around the spark plug wire.
ADUM1250ARZ
by
Ladvien.
2
layer board of
0.79x0.70
inches
(19.99x17.78
mm).
Shared on
August 1st, 2013 01:38.
An i2c or serial logic converter (5v-3.3v) that’s galvanically isolated (functionally like optoisolation). ADUM1250ARZ Breakout v1
RC Light Controller
by
laneboysrc.
2
layer board of
1.18x0.90
inches
(29.97x22.89
mm).
Shared on
August 1st, 2013 01:11.
Realistic looking lights for Radio Control (RC) cars based on PIC16F1825 and TLC5940.
See http://laneboysrc.blogspot.com/2013/09/diy-rc-light-controller-update.html for more information.
Firmware, schematics and layout files available at https://github.com/laneboysrc/rc-light-controller
