Shared projects
Linear Power Amp
by![](../../../gravatar.com/avatar/55ea3b106c3f2715c1b551a083c13489ea98.jpg?s=16)
2
layer board of
4.55x2.04
inches
(115.57x51.77
mm).
Shared on
July 31st, 2013 22:03.
Summing junction, 2 amp output
Power Module
by![](../../../gravatar.com/avatar/55ea3b106c3f2715c1b551a083c13489ea98.jpg?s=16)
2
layer board of
3.30x1.79
inches
(83.82x45.39
mm).
Shared on
July 31st, 2013 22:03.
3.3 and 5 volt with screw terminals and breadboard connections
Encoder Interface
by![](../../../gravatar.com/avatar/55ea3b106c3f2715c1b551a083c13489ea98.jpg?s=16)
2
layer board of
1.65x1.59
inches
(41.91x40.34
mm).
Shared on
July 31st, 2013 22:02.
Encoder to up down counter
moto-shield
by![](../../../gravatar.com/avatar/b48df17302f1e0341c8f758839ad04b1ea98.jpeg?s=16)
2
layer board of
2.94x2.15
inches
(74.68x54.64
mm).
Shared on
July 31st, 2013 21:29.
Raspberry pi shield. Motocycle data acquisition
myftdi
by![](../../../gravatar.com/avatar/deddfaf8398826704c6fffe6135a9cdbea98.jpg?s=16)
2
layer board of
0.64x0.61
inches
(16.26x15.52
mm).
Shared on
July 31st, 2013 20:57.
Standard ftdi rs232 usb<->serial board. In small package. Parts on both top and bottom.
Uses standard ftdi pinout.
rev2a
