Laser Vision System - Laser Control Board
by
dewhisna.
2
layer board of
2.11x2.43
inches
(53.49x61.75
mm).
Shared on
May 30th, 2017 13:56.
Laser Control Board Arduino Shield for the Laser Vision System. This board interfaces the laser PWM power modulation and on/off logic, as well as the LaserEye Reflection Sensors.
USBAVRPROG 2
by
urjaman.
2
layer board of
1.56x2.58
inches
(39.52x65.56
mm).
Shared on
May 30th, 2017 10:27.
Voltage monitor
by
sjm.
2
layer board of
0.42x0.51
inches
(10.72x12.90
mm).
Shared on
May 30th, 2017 08:04.
INA226 Voltage/Current/Power I2C interface
Squix Planespotter & Weatherstation
by
anthonyjclarke.
2
layer board of
1.98x1.68
inches
(50.32x42.70
mm).
Shared on
May 29th, 2017 22:24.
Full Project details here - https://blog.squix.org/product/esp8266-wifi-color-display-kit-2-4
APDS9500.v01a
by
PeskyProducts.
4
layer board of
0.71x0.51
inches
(17.91x12.83
mm).
Shared on
May 29th, 2017 19:00.
Broadcom’s APDS9500 gesture sensor and IR camera, redesigned layout for better breadboard use.
