BBMLX.brd
by
NW15062.
2
layer board of
2.91x1.06
inches
(73.94x26.92
mm).
Shared on
May 10th, 2017 19:51.
MOLEX 2x8 2mm x6 breakout
VME64 Backplane Breakout
by
NW15062.
2
layer board of
4.20x1.33
inches
(106.76x33.73
mm).
Shared on
May 10th, 2017 16:51.
VME64 Backplane Breakout Adapter
Toradex HMI Adapter V1.1
by
Toradex.
2
layer board of
3.55x3.94
inches
(90.14x100.15
mm).
Shared on
May 10th, 2017 06:53.
Toradex HMI Adapter is an interface board which plugs on to the Toradex Viola Plus Carrier Board and provide the following industrial interface:
- Wide range input power supply (7V-36V)
- 1x Isolated CAN Bus
- 2x Isolated half duplex RS485/MODBUS
- 1x Isolated RS232
- Upto 8x Isolated GPIO
- 1x Buzzer
- Serial Flash Memory
Click here for more details about Toradex HMI Adapter.
Button Socket
by
TreySch.
2
layer board of
1.91x2.01
inches
(48.41x50.95
mm).
Shared on
May 10th, 2017 05:33.
For LED Wall Exhibit
LED board
by
TreySch.
2
layer board of
0.90x0.90
inches
(22.89x22.89
mm).
Shared on
May 10th, 2017 05:33.
For LED Wall Exhibit
