Laen's Shift Register Demo v2
by
Jenner.
2
layer board of
4.11x1.41
inches
(104.29x35.71
mm).
Shared on
September 9th, 2016 00:27.
Provides eight output LEDs driven by an HC595 shift register with input press-buttons for data, clock, and latch to demonstrate how a shift register works.
The Github repo has the design and parts list.
This project is released under the Open Hardware License v1.2.
LCD-LiDAR-SD Teensy Hat v1.0
by
Jenner.
2
layer board of
3.16x1.43
inches
(80.16x36.35
mm).
Shared on
August 31st, 2016 02:31.
Teensy 3.2 daughter board to display the results of a LiDAR-Lite rangefinder on an LCD screen, with three buttons, two LEDs, and a micro-SD card for datalogging.
The Github repo has the design and parts list.
This project is released under the Open Hardware License v1.2.
Input Power Board (SMT) v1.1
by
Jenner.
2
layer board of
1.53x1.15
inches
(38.76x29.11
mm).
Shared on
August 30th, 2016 05:36.
Breadboard-compatible board breaks out 9V, 5V, and 3.3V from a 9V battery using both through-hole and surface-mount components.
This is a good, useful design to practice soldering surface-mount parts. The pads are wide enough for reflow or a soldering iron.
Check out the Github repo for parts and assembly information.
This project is released under the Open Hardware License v1.2.
Temperature Monitor Teensy Hat v1.0
by
Jenner.
2
layer board of
3.17x1.43
inches
(80.42x36.22
mm).
Shared on
August 30th, 2016 04:33.
Teensy 3.2 daughter board to display a thermocouple temperature on an LCD screen.
The Github repo has the design and parts list.
This project is released under the Open Hardware License v1.2.
Seven-Segment Display Teensy Hat v1.0
by
Jenner.
2
layer board of
1.47x0.72
inches
(37.24x18.19
mm).
Shared on
August 30th, 2016 04:31.
Teensy 3.2 daughter board for a 4x7-Segment Display.
The Github repo has the design and parts list.
This project is released under the Open Hardware License v1.2.
