JAFaR - base module v4.1
by
mikym0use.
2
layer board of
1.69x1.15
inches
(42.93x29.21
mm).
Shared on
April 24th, 2017 07:21.
http://www.rcgroups.com/forums/showthread.php?t=2619124 THIS PCB IS UNTESTED use this pcb at you own risk!
Meikelino V2.0 Final
by
Meikel.
2
layer board of
2.71x2.11
inches
(68.83x53.62
mm).
Shared on
April 24th, 2017 06:56.
PIC basiert in Arduino UNO Größe - PIC based in Arduino UNO Size
Getestet in Ordnung - Tested okay
Per ICSP oder via Bootloader programmierbar
Menge Wert Bauteile
3 x LED SMD-0805 - PWR, RX, TX
3 x 1K Widerstand SMD-0805 - R1, R2, R5
2 x 10K Widerstand SMD-0805 - R3, R8
1 x 470R Widerstand SMD-0805 - R4
2 x 100R Widerstand SMD-0805 - R6, R7
1 x Resonator-SMD 12MHz - X1
1 x SMD-Quarz - X2 * je nach gewähltem PIC18F 8/10/16MHz
2 x 15p Chip-Kondensator 0805 - C6, C7
6 x 100n Chip-Kondensator 0805 - C3, C4, C8, C9, C10, C11
2 x 22µ CPOL-SMD Bauform B - C2, C5
1 x 47µ CPOL-SMD Bauform D - C1
1 x 500mA Sicherung rückstellend SMD0805 - F1
1 x MCP39100-5.0WS - U1
1 x MCP39100-3.3WS - U2
1 x PIC18FxxKxx - U3
1 x MCP2200SOIC - U4
1 x Diode SA26A - D1
2 x Diode SS13L - D2, D3
1 x MINI-USB SMD - USB
1 x HOHLBUCHSE 2,1x5,5 - DC_IN
1 x Tactile Kurzhubtaster 6mm - S2
1 x Jumper 2-polig - RTS
1 x Jumper 3-polig - RB1/GND
1 x Buchsenleiste 8-polig - SV1, SV3, SV4, SV5
1 x Buchsenleiste 6-polig - SV2
1 x Buchsenleiste 4-polig - SV7
1 x Stiftleiste 90° gewinkelt 6-polig - SV6
Charlie's AlienWhoop F4
by
AlienWhoop.
2
layer board of
1.15x1.15
inches
(29.21x29.21
mm).
Shared on
April 24th, 2017 04:49.
AlienFlight F4 remixed for Tiny Whoop/Inductrix
Note: Don’t forget to choose 2oz 0.8mm PCB
