OSH Park
Shared projects
Bluesaab RN52 v5.3
by
homerisback.
2
layer board of
2.44x2.44
inches
(61.98x62.00
mm).
Shared on
April 22nd, 2017 17:10.
CDC Emulator for older SAABs 9-3 & 9-5
ZM1042 Nixie breadboard adapter
by
judge2005.
2
layer board of
1.31x1.31
inches
(33.15x33.17
mm).
Shared on
April 22nd, 2017 16:04.
A breadboard adapter for a ZM1042 Nixie tube. The ZM1042 has 1mm pins that plug in to a socket. This board is intended to use female D-SUB pins as a ‘socket’. These are often listed on eBay as ‘tube socket pins’.
6844A Nixie breadboard adapter
by
judge2005.
2
layer board of
1.31x1.31
inches
(33.17x33.17
mm).
Shared on
April 22nd, 2017 16:04.
Breadboard adapter for 6844A nixie tube. The 6844A has 1mm pins that plug in to a socket. This board is intended to use female D-SUB pins as a ‘socket’. These are often listed on eBay as ‘tube socket pins’.
esp-link
by
flegi.
2
layer board of
0.79x0.99
inches
(20.02x25.02
mm).
Shared on
April 22nd, 2017 15:17.
http://go.flegl.net/esp-link
STIXperimenter 1.0
by
Hustin13.
2
layer board of
2.19x2.20
inches
(55.55x55.88
mm).
Shared on
April 22nd, 2017 09:56.
Board to facilitate intercepting signals to an Intellivision STIC chip
