HydraLINCAN
by
smillier.
2
layer board of
2.37x1.47
inches
(60.22x37.21
mm).
Shared on
April 10th, 2017 08:02.
Hydrabus Shield for CAN and LIN Bus analysis. More details on www.hydrabus.com and https://github.com/smillier/HydraLINCAN
solarcharger.v01c
by
PeskyProducts.
2
layer board of
0.51x0.51
inches
(12.83x12.83
mm).
Shared on
April 9th, 2017 23:27.
More or less the reference design in terms of layout at a still-small size.
RGB_LED_MATRIX.zip
by
Thyristor.
2
layer board of
2.06x2.06
inches
(52.22x52.22
mm).
Shared on
April 9th, 2017 22:02.
RGB LED Matrix for FPGA EP2C5T144mini PCB
https://github.com/Thyristor/RGB-LED-Matrix-for-FPGA-EP2C5T144mini-PCB
EachiWhoop v2
by
Vladisenko.
2
layer board of
0.46x1.43
inches
(11.76x36.32
mm).
Shared on
April 9th, 2017 18:56.
Second version of micro size flight controller board for Eachine E010 frame. Now with support FlySky AFHDS A2 protocol with telemetry. Weight is only 1.18 grams.
Note: choose “2oz 0.8mm” option.
StackLightMonitor.brd
by
dkt01.
2
layer board of
1.99x1.98
inches
(50.44x50.37
mm).
Shared on
April 9th, 2017 17:30.
Arduino Pro Micro shield to drive LES-302 AW stack lights
