OSH Park
Shared projects
TempControllerSMD
by
BudBennett.
2
layer board of
1.82x2.96
inches
(46.20x75.26
mm).
Shared on
July 22nd, 2014 01:03.
16 Channel analog/digital I/O board for Raspberry Pi
4xFilterL
by
k3pto.
2
layer board of
2.61x3.36
inches
(66.19x85.24
mm).
Shared on
July 22nd, 2014 00:00.
4 band audio filter
Pwr-PreAmp
by
k3pto.
2
layer board of
2.01x3.01
inches
(50.95x76.35
mm).
Shared on
July 22nd, 2014 00:00.
Power Supply and PreAmp for Spectrum Display
tv be gone
by
Frank_Red.
2
layer board of
1.39x0.90
inches
(35.26x22.86
mm).
Shared on
July 21st, 2014 21:01.
tv be gone mini
Big Purple Driver, Rev. 3
by
msds.
2
layer board of
1.80x1.60
inches
(45.72x40.64
mm).
Shared on
July 21st, 2014 20:42.
This board is a meta-breakout board for Pololu’s DRV8825 stepper driver module, designed to hold a custom-machined heatsink, capacitor, screw-terminal connectors, and an indicator LED for fault conditions.
C1 is a Panasonic H13 100µF 63V electrolytic capacitor (EEE-TK1J101AQ).
D1 is an 1206 red LED - OSRAM’s LH N974-KN-1
Q2 is a P-channel MOSFET - NXP BSS84,215. Q1 and R1 are non-existent.
R2 is an appropriately-sized 0805 current-limiting resistor for your choice of LED.
JP3 and JP4 are 2 and 4 position 3.5mm screw terminals. Phoenix 5452604 and TE 284391-2 work.
