MSGEQ7 Breakout
by
Aerospacesmith.
2
layer board of
0.99x0.63
inches
(25.02x16.00
mm).
Shared on
July 20th, 2014 04:35.
Breakout Board for the MSGEQ7. BoM: 2x100nF Cap,1x10nF Cap, 1x33pF Cap, 1x200kOhm Res, 1xMSGEQ7 and/or Socket, 1x6pin header
Adaptive Node Development Board
by
saporis.
2
layer board of
1.96x2.00
inches
(49.81x50.70
mm).
Shared on
July 19th, 2014 23:43.
When testing multiple Adaptive Nodes before sending to market or by testing against a scope, this is the board you need. This requires an Adaptive Node SMD board to be attached.
LiPoChargerTeensy3.1.V01
by
2
layer board of
0.71x0.31
inches
(17.91x7.75
mm).
Shared on
July 19th, 2014 19:44.
LiPo charger add-on shield for Teensy 3.1
GPS Pi Plate v0.1
by
nsayer.
2
layer board of
1.05x1.35
inches
(26.67x34.29
mm).
Shared on
July 19th, 2014 19:40.
GPS serial and PPS for Raspberry Pi.
Takes an AdaFruit Ultimate GPS module and connects RX and TX to the GPIO serial pins (optionally - solder jumpers to disconnect them are on the board), the PPS output to GPIO 18, adds a CR1220 battery clip on the bottom for warm-start, a U.FL connector for an external GPS antenna and a FIX LED.
FYC PCB 130
by
goseese.
2
layer board of
1.10x1.50
inches
(28.04x38.20
mm).
Shared on
July 19th, 2014 19:39.
FYC Relay and break out PCB
