shaft encoder splitter/isolator
by
KD7MRX.
2
layer board of
2.00x2.00
inches
(50.75x50.75
mm).
Shared on
June 8th, 2014 05:17.
send the output of a shaft encoder to two devices without creating a ground loop
Freemo Switch board
by
cstalsworth.
2
layer board of
1.33x0.72
inches
(33.81x18.24
mm).
Shared on
June 8th, 2014 01:31.
Wire board for switch control on module
blinkenthing B
by
0x263a.
2
layer board of
2.12x2.37
inches
(53.77x60.10
mm).
Shared on
June 8th, 2014 00:10.
http://haldean.org/bike
Fet Driver Board Rev1.3.3 Gerber 1 _Multiwii
by
Midelic.
2
layer board of
0.92x0.70
inches
(23.27x17.81
mm).
Shared on
June 7th, 2014 23:25.
multiwii brushed designed by Blackmoon on RCG
Quadcopter Power Distribution Board kit
by
gcardinal.
2
layer board of
2.02x2.02
inches
(51.21x51.21
mm).
Shared on
June 7th, 2014 22:26.
This quadcopter PDB can be used with any frame. It distributes power from the flight battery to ESCs to power the Quad’s motors.
