B-5971 Nixe Tube - SmartDriver (3of3)
by
radmeck.
2
layer board of
1.64x1.56
inches
(41.68x39.62
mm).
Shared on
June 9th, 2014 18:30.
Driver Board for Burroughs B-5971 Alphanumeric Nixie Tube
- PIC16F690 Running SmartSocket Code
- Plugs into back of B-5971 Nixie Tube - SmartLink at 90°
- Based on B7971 V2 - Chris/fixitsan2
- Thanks to Sjef van Gool for cathode resistor values
- Project Files: B-5971_SmartSockets.zip
- More Info: Smartsockets Yahoo Group
ADS-B bandpass filter with LNA
by
goboxgizmos.
2
layer board of
4.14x1.80
inches
(105.26x45.72
mm).
Shared on
June 9th, 2014 16:59.
RGB to Component Through Hole v1.0
by
Helder.
2
layer board of
1.30x1.49
inches
(33.02x37.80
mm).
Shared on
June 9th, 2014 13:58.
Uses NPN 2N3904 Transistors
WRGB LED PCB
by
Mattaus.
2
layer board of
0.64x0.64
inches
(16.28x16.28
mm).
Shared on
June 9th, 2014 11:13.
WRGB LED PCB for Cree XQE LEDs
26mm AMC7135 Slave
by
Mattaus.
2
layer board of
1.03x1.03
inches
(26.26x26.26
mm).
Shared on
June 9th, 2014 11:12.
20x7135 Chips, 26mm in Diameter
