Pi Supply Switch v1.1
by
jwalton.
2
layer board of
1.75x1.17
inches
(44.32x29.82
mm).
Shared on
January 31st, 2014 16:09.
http://www.pi-supply.com/product/pcb-party/
DAC / RS485 and OLED Arduino Shield
by
hallard.
2
layer board of
2.36x2.11
inches
(59.82x53.47
mm).
Shared on
January 31st, 2014 12:46.
0-10V DAC / ADC / RS485 and OLED Arduino Shield
This is a simple board to be able to
- Generate 4 x 0-10V analog output to drive industrial devices
- 2 x 0-10V analog input (unprotected)
- A RS485 Driver (use RX/TX of Arduino)
- 2 x I2C Oled connector (Adafruit or Tindie Oled)
- 1 Rotary Encoder
- 1 WS2812B RGB Led
This is a proto board, I’ve just ordered one on OSHPark, will put more details once received and tested
Detailed Description
Everything will be documented on myblog
Schematics and board and more informations on my github repo
Check out news and other projects on my blog
Breakout+USB
by
DX-MON.
2
layer board of
3.20x2.55
inches
(81.36x64.80
mm).
Shared on
January 30th, 2014 22:20.
A breakout and programmer board for an ARM Cortex-M3 based processor
Mailchecker II
by
kuy.
2
layer board of
1.05x1.26
inches
(26.57x32.03
mm).
Shared on
January 30th, 2014 20:42.
This Electric Imp-powered device detects motion and reports it to you over the web.
It was originally designed to be stuck to a mailbox door to notify you over WiFi when mail is delivered. It could also be used to monitor doors (including garage or pet doors), valuables that you don’t want moved or cookie jars you want to keep children out of.
The board features an accelerometer, light sensor and Lithium-ion/polymer battery recharging built in. It achieves approximately one month of use between charges per 100mAh of battery capacity, assuming two motion activations per day.
This is a totally valid design but I intend to publish a newer version with Li-ion battery protection for unregulated cells.
Design files, schematics, BOM and source code on Github
emg-bridge_rev1
by
ixjlyons.
2
layer board of
3.60x2.00
inches
(91.47x50.80
mm).
Shared on
January 30th, 2014 19:50.
EMG power and signal distribution board
