LS_Active
by
TenM.
2
layer board of
3.71x2.09
inches
(94.31x53.04
mm).
Shared on
November 14th, 2013 10:02.
Active speaker processing board
Valve amplifier warm-up delay
by
TenM.
2
layer board of
6.30x3.94
inches
(160.05x100.03
mm).
Shared on
November 14th, 2013 10:02.
Valve amplifier warm-up delay with display unit
UV5R TRRS Adapter
by
chrishood.
2
layer board of
1.08x0.32
inches
(27.36x8.15
mm).
Shared on
November 13th, 2013 23:59.
Almost an exact duplicate of the original, all I did was change the ground to a ground plane on the bottom of the board, to hopefully help with some signal shielding. Please see the original at https://github.com/johnboiles/BaofengUV5R-TRRS. Thank you John.
BOM:
1x 3.5mm Stereo Cable
1x 2.5mm Stereo Cable
1x 3.5mm TRRS Cable
1x 10k Resistor 0603
2x 2.2k Resistor 0603
2x .01uF Capacitor 0603
Ferm Control RevC
by
LordUlrich.
2
layer board of
4.12x1.48
inches
(104.55x37.49
mm).
Shared on
November 13th, 2013 22:41.
Fermentation Temp Controller
logi-cam2-noffc-ra2
by
valentfx.
2
layer board of
1.73x1.40
inches
(43.94x35.46
mm).
Shared on
November 13th, 2013 20:35.
