Motherboard Squad Developer Board
by
Josh-Jetter.
2
layer board of
1.95x2.09
inches
(49.53x53.04
mm).
Shared on
November 20th, 2013 06:12.
Evaluation board for the MK10DN512ZVLL10.
5V/12V Optical Speed Sensor
by
fugalster.
2
layer board of
1.00x0.80
inches
(25.43x20.32
mm).
Shared on
November 20th, 2013 05:06.
Uses an Optek reflective sensor to detect light/dark transitions, presumably stripes on a wheel. Output is filtered through a schmitt trigger. Supply it with voltage as indicated and get TTL compatible output.
Where a value contains a “/” the number preceding the “/” is to be used when powered with 5V and the number following the “/” is to be used when powered with 12V.
Output current should be kept less than 35mA with 5V supply or 10mA with 12V supply. In either case the output voltage will remain within TTL standards (2.8V – 5V for HIGH condition).
GI Buddy Final
by
dkpinball.
2
layer board of
0.61x1.18
inches
(15.39x29.97
mm).
Shared on
November 19th, 2013 20:09.
Pinball GI Driven Switch
petitAVR-v1
by
khyale.
2
layer board of
0.83x1.53
inches
(21.08x38.89
mm).
Shared on
November 19th, 2013 19:02.
Small circuit board for Atmega328P applications
ece411-t15-Out-of-Beer-
by
Practicum-T15.
2
layer board of
3.94x3.15
inches
(100.00x80.01
mm).
Shared on
November 19th, 2013 17:40.
2013 Practicum T15
