Tiny Trackuino
by
johnboiles.
2
layer board of
1.96x1.88
inches
(49.73x47.70
mm).
Shared on
October 12th, 2013 00:38.
Small Trackuino-compatible board for transmitting APRS packets over 2m amateur radio.
Firmware
The firmware is available at github.com/johnboiles/trackuino. It is modified from the original Trackuino firmware in order to support the newer 32u4 processors.
Bill of Materials
2x Screw Terminals 3.5mm Pitch (2-Pin)
1x Screw Terminals 3.5mm Pitch (3-Pin)
1x SMA Female Thru Hole Connector
1x EM406 (JST-SH) Horizontal Connector
1x 5V GPS with JST-SH connector
1x JST-SH Cable
1x Radiometrix HX1 Transmitter
1x 10k Resistor 0603
1x 3.3k Resistor 0603
1x 1k Resistor 0603
2x 10uF Capacitor 1206
mchck 20130829
by
cmason.
2
layer board of
1.87x0.74
inches
(47.55x18.90
mm).
Shared on
October 11th, 2013 20:36.
a326299b0214aea1bfc0ae8a851930b46a0be483
UNO SUPER PROTO BOARD
by
ucschmidt.
2
layer board of
3.11x2.11
inches
(78.89x53.49
mm).
Shared on
October 11th, 2013 19:21.
UNO SUPER PROTO BOARD
OpenUPS to XLR power distribution board
by
bootc.
2
layer board of
2.65x3.10
inches
(67.34x78.77
mm).
Shared on
October 11th, 2013 13:18.
MiniFIT-JR sockets to 3-pin locking XLR with TVS diodes, capacitors and polyfuses for protection
PCC Class
by
hydronics.
2
layer board of
1.30x0.79
inches
(32.89x20.12
mm).
Shared on
October 11th, 2013 04:40.
8806 LED driver board w/ attiny85
