Pcbcart Gh60 Rev B V2
by
domoaligato.
2
layer board of
11.23x3.73
inches
(285.12x94.72
mm).
Shared on
October 10th, 2013 21:01.
Pcbcart Gh60 Rev B V2
Keyboard PC
by
bombTECH-Research-and-Development.
2
layer board of
4.05x0.90
inches
(102.90x22.89
mm).
Shared on
October 10th, 2013 20:23.
Keyboard PC - ATMEGA323+PIC16F mini computer
Composite Video Output MINI DIN 6 Keyboard Connector 64Mbit Flash Memory
PIC16F handles video (along with a 16x4 FIFO buffer). ATMEGA323 handles keyboard, flash, and general processing. NO POWER JACK! You have to wire a 7V 1600mA (minimum) power source to both regulator input pins.
HaDuino
by
Benchoff.
2
layer board of
2.84x2.12
inches
(72.19x53.77
mm).
Shared on
October 10th, 2013 16:52.
The official Hackaday Arduino-compatible dev board
Lettera
by
pietroleoni.
2
layer board of
2.70x2.10
inches
(68.63x53.37
mm).
Shared on
October 10th, 2013 08:46.
8bit cnc arduino board: 2 stepper, 2 endstops, 1 servo http://pietroleoni.com/lettera
Final Original Timer V1.0
by
taylorsorensen.
2
layer board of
2.18x5.90
inches
(55.42x149.91
mm).
Shared on
October 10th, 2013 02:16.
