OSH Park
Shared projects
Mirage335BiosignalAmplifier_Host
by
mirage335.
2
layer board of
2.96x3.19
inches
(75.18x80.90
mm).
Shared on
October 15th, 2013 18:34.
Signal isolation and acquisition board. http://mirage335.dyndns.org/wiki/Mirage335BiosignalAmp
Mirage335BiosignalAmplifer_ActiveElectrode
by
mirage335.
2
layer board of
0.96x1.20
inches
(24.41x30.35
mm).
Shared on
October 15th, 2013 18:34.
Active electrode. Build a pair. http://mirage335.dyndns.org/wiki/Mirage335BiosignalAmp
Mirage335BiosignalAmplifier_Amplifier
by
mirage335.
4
layer board of
3.41x2.38
inches
(86.64x60.58
mm).
Shared on
October 15th, 2013 18:33.
Analog signal processor board. Four layers. http://mirage335.dyndns.org/wiki/Mirage335BiosignalAmp
Turntable Controller
by
KMNR.
2
layer board of
2.50x3.50
inches
(63.50x88.90
mm).
Shared on
October 15th, 2013 12:58.
A clone of the Henry Engineering Universal Turntable Controller
mcp73831_Max5434_charger
by
rkovvuri.
2
layer board of
0.52x0.42
inches
(13.16x10.67
mm).
Shared on
October 15th, 2013 12:35.
This is an experimentation board for using MCP73831 Li-Ion charger with a digital pot . It allows the charge current control through a microcontroller.
