BB LPC812 V2.2
by
cpldcpu.
2
layer board of
1.10x0.60
inches
(27.94x15.27
mm).
Shared on
September 29th, 2013 11:53.
Breakout Board for the LPC812 Cortex M0+ Microcontroller
CC-SGrB
by
Corypclifton.
2
layer board of
1.34x3.40
inches
(34.11x86.31
mm).
Shared on
September 28th, 2013 20:17.
A small signal generator from diystompboxes.com
ID-12 Railbreakout
by
pyth.
2
layer board of
3.32x1.06
inches
(84.30x26.82
mm).
Shared on
September 28th, 2013 18:35.
Board for mounting ID 12 RFID Module under M or C track
tonebender mkii
by
derevaun.
2
layer board of
2.20x0.80
inches
(55.88x20.32
mm).
Shared on
September 28th, 2013 05:01.
Verified!
Compact layout with bias brought out to a pot. Schematic is based on the ilovefuzz.com schematic, with a 25k pot replacing the 8k resistor at the collector of Q3. Transistor pinouts are all CBE with collectors closest to the pots. C6 is a tight fit behind the pot–not a good place for busting out the mojo!
Loststone_sensor
by
major.
2
layer board of
1.90x1.90
inches
(48.21x48.16
mm).
Shared on
September 28th, 2013 01:17.
Loststone sensor board http://majoros.github.io/loststone
Open source trackball http://chris.majoros.us/mmdh/?page_id=141
