dt750
by
rkovvuri.
2
layer board of
0.55x0.79
inches
(14.05x20.04
mm).
Shared on
September 25th, 2013 16:01.
This is a mounting board for the Turnigy DT750 motor. It brings in all the 3 wires to the board instead of them dangling.
ppm encoder
by
rkovvuri.
2
layer board of
0.77x0.81
inches
(19.43x20.52
mm).
Shared on
September 25th, 2013 15:59.
ppm encoder for rc radio receivers
Tiny Header Board 1.2 m1
by
boyanov.
2
layer board of
0.90x1.20
inches
(22.96x30.58
mm).
Shared on
September 25th, 2013 11:52.
Tiny header board for the Atmel AVR ATTiny chips in DIP-8 such as ATTiny 25/45/85.
The goal is to have a board that you can start using right a way, contains the minimum required components to run properly and will even let you prototype simple projects without using a breadboard.
Circuit located at 123d.circuits.io
OLED Shield
by
jedhodson.
2
layer board of
2.34x2.15
inches
(59.39x54.61
mm).
Shared on
September 25th, 2013 06:07.
An Arduino shield for freetronics OLED Display. Contains Proto area and two connecters for OLED – 1.Direct Connection and 2.Cable Connection.Created 25/09/13 ©Jed Hodson 2013
QA400 frontend
by
prettygoodaudio.
2
layer board of
8.60x2.00
inches
(218.49x50.85
mm).
Shared on
September 25th, 2013 00:40.
front-end for the quantasylum qa400 audio analyzer to make it useful in a pro-audio context. schematic here.
