FTDI MINI
by
DrYerzinia.
2
layer board of
0.93x0.88
inches
(23.49x22.23
mm).
Shared on
August 28th, 2013 03:56.
USB to Serial converter circuit board. For more details look on my site
ATTiny 85 Breakout Board
by
mikebrowning.
2
layer board of
0.71x0.63
inches
(18.06x16.00
mm).
Shared on
August 28th, 2013 00:47.
ATTiny 85 Breakout Board with ISP
AC48
by
The-LED-Artist.
2
layer board of
2.37x2.37
inches
(60.15x60.15
mm).
Shared on
August 27th, 2013 19:08.
Goodfet42
by
Danukeru.
2
layer board of
1.89x0.78
inches
(47.96x19.68
mm).
Shared on
August 27th, 2013 05:53.
Travis Goodspeed’s universal IC interface adapter. JTAG, SPI, OpenOCD, and more!
http://goodfet.sourceforge.net/hardware/goodfet42/
Die Datenkrake
by
Danukeru.
4
layer board of
4.58x3.30
inches
(116.23x83.85
mm).
Shared on
August 27th, 2013 05:53.
Tentacles all over your buses. Hardware sniffer and fuzzer.
https://github.com/ddk
