Inline Amplifier
by
DrYerzinia.
2
layer board of
1.51x3.41
inches
(38.25x86.64
mm).
Shared on
August 29th, 2013 06:14.
This board uses a LM386 chip to boost small audio signals to higher levels for speakers or input to other devices. For more details take a look at my site
Bargraph Panel Mount
by
rherman.
2
layer board of
3.02x0.96
inches
(76.71x24.41
mm).
Shared on
August 28th, 2013 07:47.
This enables the display of Sparkfun’s bargraph kit to be panel-mounted with ribbon cables running to the kit’s board. With the resistors attached to this board, the kit’s board also can be cut down to reduce its footprint.
MAX5436 Breakout
by
rherman.
2
layer board of
0.45x0.42
inches
(11.46x10.57
mm).
Shared on
August 28th, 2013 07:45.
breakout board for the MAX5436 digital pot
Joystick Breakout
by
rherman.
2
layer board of
0.94x0.61
inches
(23.75x15.52
mm).
Shared on
August 28th, 2013 07:45.
compact version of Sparkfun’s joystick breakout board
Nav Switch
by
rherman.
2
layer board of
0.74x0.51
inches
(18.80x12.83
mm).
Shared on
August 28th, 2013 07:44.
compact version of Sparkfun’s nav switch breakout board
